o
When 5.1-channel speakers are installed
.
z1
z2
FL
SW
C
SL
FR
SR
z1 22° - 30° z2 120°
o
Layout including height speakers and ceiling
speakers
n
Height speaker layout example
Combination of 5.1-channel layout and front height/rear height/center
height speakers.
.
FHL FHR
C
FL FR
SW
SL SR
RHL RHR
CH
Contents
Connections Playback Settings Tips Appendix
38
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X6700H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X6700H and is the answer not in the manual?

Denon AVR-X6700H Specifications

General IconGeneral
Channels11.2
Power Output140W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Speaker Impedance4-16 ohms
Input Sensitivity/Impedance200mV / 47k ohms
HDMI Inputs8
HDMI Outputs3
HDCP SupportHDCP 2.3
HDR CompatibilityHDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)eARC
Video Upscaling8K
BluetoothYes
Wi-FiYes
EthernetYes
Voice Assistant SupportAmazon Alexa, Google Assistant, Apple Siri
Phono InputYes
Zone Audio Output3 Zones
Room CalibrationAudyssey MultEQ XT32
Frequency Response10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion0.05%
Signal-to-Noise Ratio102dB
HDMI Support4K/120Hz, 8K/60Hz
USB Port1
Streaming ServicesAirPlay 2, HEOS, Spotify, Tidal, Deezer, Amazon Music, Pandora, SiriusXM
Audio DecodingDolby Atmos, DTS:X, Auro-3D
