Bi-amp connection
o
9.1-channel playback (bi-amp connection of front speakers)
This system plays back 9.1-channels. You can use the bi-amp connection for front speakers. Bi-amp connection is a method to connect separate
amplifiers to the tweeter terminal and woofer terminal of a speaker that supports bi-amplification. This connection enables back EMF (power returned
without being output) from the woofer to flow into the tweeter without affecting the sound quality, producing a higher sound quality.
.
FHL
SW
C
SL
SBL
FHR
SR
SBR
FL
(Bi-Amp)
FR
(Bi-Amp)
NOTE
0
When making bi-amp connections, be sure to remove the short-circuiting plate or
wire between the speaker’s woofer and tweeter terminals.
.
ASSIGNABLE
FRONT FRONT
CENTER
SURROUND SURROUND
HEIGHT1 HEIGHT1
ASSIGNABLE
SURROUND BACK SURROUND BACK
ASSIGNABLE
ASSIGNABLE
SPEAKERS
ASSIGNABLE
wqwq
(R) (L)
SW
SBR SBL FHR FHL
CSRSL
FLFR
zz
z
The height speakers, ceiling speakers and Dolby Atmos Enabled speakers can
be connected to the HEIGHT1 speaker terminals. Set the speaker to be
connected from “Height” - “Layout” in the menu. (v p. 242)
Contents
Connections Playback Settings Tips Appendix
73
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X6700H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X6700H and is the answer not in the manual?

Denon AVR-X6700H Specifications

General IconGeneral
Channels11.2
Power Output140W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Speaker Impedance4-16 ohms
Input Sensitivity/Impedance200mV / 47k ohms
HDMI Inputs8
HDMI Outputs3
HDCP SupportHDCP 2.3
HDR CompatibilityHDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)eARC
Video Upscaling8K
BluetoothYes
Wi-FiYes
EthernetYes
Voice Assistant SupportAmazon Alexa, Google Assistant, Apple Siri
Phono InputYes
Zone Audio Output3 Zones
Room CalibrationAudyssey MultEQ XT32
Frequency Response10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion0.05%
Signal-to-Noise Ratio102dB
HDMI Support4K/120Hz, 8K/60Hz
USB Port1
Streaming ServicesAirPlay 2, HEOS, Spotify, Tidal, Deezer, Amazon Music, Pandora, SiriusXM
Audio DecodingDolby Atmos, DTS:X, Auro-3D
