Combinations of height speakers to be used
Connected speaker terminals
Number of
height / ceiling
speakers
Number of Dolby
Speakers
Combination pattern HEIGHT1 HEIGHT2
HEIGHT 3/
FRONT WIDEz1
6ch
6ch None
Front Height & Surr. Height & Rear
Heightz4
Front Height Rear Height Surr. Height
Front Height & Rear Height & Top
Surround & Center Heightz3
Front Height Rear Height
L: Top Surround
R: Center Height
Front Height & Surr. Height & Top
Surround & Center Height
Front Height Surr. Height
L: Top Surround
R: Center Height
Front Height & Top Middle & Rear
Heightz3z5
Front Height Rear Height Top Middle
Top Front & Top Middle & Top
Rearz5
Top Front Top Rear Top Middle
4ch 2ch
Front Height & Surr. Dolby & Rear
Heightz3
Front Height Rear Height Surround Dolby
Top Front & Surr. Dolby & Top Rear Top Front Top Rear Surround Dolby
2ch 4ch
Front Height & Surr. Dolby & Back
Dolbyz2
Front Dolby Back Dolby Surround Dolby
Front Dolby & Top Middle & Back
Dolbyz2
Front Dolby Back Dolby Top Middle
Front Dolby & Surr. Dolby & Rear
Height
Front Dolby Rear Height Surround Dolby
None 6ch
Front Dolby & Surr. Dolby & Back
Dolbyz2
Front Dolby Back Dolby Surround Dolby
z1 Connect to the HEIGHT3/FRONT WIDE speaker terminal to use Front Wide speakers. Set “Floor” in the menu to “5ch & FW” or “5ch & SB & FW”. (v p. 240)
z2
This combination can be selected when using Surround Back speakers.
z3
For the best Auro-3D experience Surround Height speakers are recommended, however you may substitute Rear Height speakers from a Dolby Atmos speaker setup in
place of Surround Height speakers.
z4
Use 2 sets of Height speakers in the appropriate sound modes for Dolby Atmos, DTS:X or Auro-3D playback.
Use the Front Height and Rear Height speakers for Dolby Atmos or DTS:X playback.
Use the Front Height and Surround Height speakers for Auro-3D playback.
z5 This combination can be selected when “Floor” in the menu to “5ch” or “5ch & SB”. (v p. 240)
