INPUT MODE
Set the audio input modes for each input source.
It is normally recommended to set the audio input mode to “AUTO”.
AUTO
(Default):
Automatically detect input signal and
perform playback.
HDMI: Play only signals from HDMI input.
DIGITAL: Play only signals from digital audio input.
ANALOG: Play only signals from analog audio input.
0
When digital signals are properly input, the ~ indicator lights on the display.
If the ~ indicator does not light, check “Input Assign” and the connections.
(v p. 222)
0
If “HDMI Control” is set to “On” and a TV compatible with the ARC is
connected via the HDMI MONITOR 1 connectors, the input mode whose input
source is “TV Audio” is fixed to ARC.
0
When an eARC function-compatible television is connected to the HDMI
MONITOR 1 connector, the input mode whose input source is “TV Audio” is
fixed to eARC.
o
Set Defaults
The “Input Assign” settings are returned to the default settings.
Contents Connections Playback Settings Tips Appendix
224
Front panel Display Rear panel Remote Index

Denon AVR-X6700H Specifications

General

Channels	11.2
Power Output	140W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Speaker Impedance	4-16 ohms
Input Sensitivity/Impedance	200mV / 47k ohms
HDMI Inputs	8
HDMI Outputs	3
HDCP Support	HDCP 2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Video Upscaling	8K
Bluetooth	Yes
Wi-Fi	Yes
Ethernet	Yes
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Phono Input	Yes
Zone Audio Output	3 Zones
Room Calibration	Audyssey MultEQ XT32
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05%
Signal-to-Noise Ratio	102dB
HDMI Support	4K/120Hz, 8K/60Hz
USB Port	1
Streaming Services	AirPlay 2, HEOS, Spotify, Tidal, Deezer, Amazon Music, Pandora, SiriusXM
Audio Decoding	Dolby Atmos, DTS:X, Auro-3D
