Denon AVR-X6700H User Manual

3
Connect the Sound calibration microphone to the
SETUP MIC jack of this unit.
.
When the Sound calibration microphone is
connected, the following screen is displayed.
.
Audyssey Setup
Dolby Speaker Setup
Channel Select
Amp Assign
Start
Your AV receiver can automatically measure the acoustics of
your room then optimize your speakers using the included
microphone and microphone stand.
Set the following items
if necessary.
4
Select “Start”, then press ENTER.
Audyssey
®
Setup can also make the following settings.
0
Amp Assign
The signals output from the SURROUND BACK, HEIGHT1,
HEIGHT2 and HEIGHT3/FRONT WIDE speaker terminals can be
switched in accordance with your speaker environment. (“Amp
Assign” (v p. 238))
0
Channel Select
If channels that are not to be used are set in advance,
measurement for the set channels is skipped, and measuring
time can be reduced. You can also change the number of
surround back speakers and subwoofer.
0
Dolby Speaker Setup
Set the distance between the Dolby Atmos Enabled speaker and
the ceiling.
This can be set when using the Front Dolby Atmos Enabled,
Surround Dolby Atmos Enabled or Back Dolby Atmos Enabled
speaker.
5
Follow the instructions on the screen display and press
“Next” to proceed further.
Contents Connections Playback Settings Tips Appendix
230
Front panel Display Rear panel Remote Index

Denon AVR-X6700H Specifications

General

Channels	11.2
Power Output	140W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Speaker Impedance	4-16 ohms
Input Sensitivity/Impedance	200mV / 47k ohms
HDMI Inputs	8
HDMI Outputs	3
HDCP Support	HDCP 2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Video Upscaling	8K
Bluetooth	Yes
Wi-Fi	Yes
Ethernet	Yes
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Phono Input	Yes
Zone Audio Output	3 Zones
Room Calibration	Audyssey MultEQ XT32
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05%
Signal-to-Noise Ratio	102dB
HDMI Support	4K/120Hz, 8K/60Hz
USB Port	1
Streaming Services	AirPlay 2, HEOS, Spotify, Tidal, Deezer, Amazon Music, Pandora, SiriusXM
Audio Decoding	Dolby Atmos, DTS:X, Auro-3D
