Denon AVR-X6700H User Manual

Settings AUDIO OUT connectors
Height Sp Dolby Sp NOTE Front Layout Middle Layout Rear Layout HEIGHT 1 HEIGHT 2
HEIGHT 3/
FRONT WIDE
4ch 2ch
z3 z6
Front Height Surround Dolby Rear Height Front Height Rear Height Surround Dolby
Top Front Surround Dolby Top Rear Top Front Top Rear Surround Dolby
2ch 4ch
z3 z6
Front Height Surround Dolby
Back Dolbyz1
Front Height Back Dolby Surround Dolby
Front Dolby Top Middle
Back Dolbyz1
Front Dolby Back Dolby Top Middle
Front Dolby Surround Dolby Rear Height Front Dolby Rear Height Surround Dolby
None 6ch
z3 z6
Front Dolby Surround Dolby
Back Dolbyz1
Front Dolby Back Dolby Surround Dolby
z1
This can be selected when using Surround Back speakers.
z2
For the best Auro-3D experience Surround Height speakers are recommended, however you may substitute Rear Height speakers from a Dolby Atmos speaker setup
in place of Surround Height speakers.
z3 This can be set when “Assign Mode” in the menu is set to “13.1ch” or “11.1ch”. (v p. 238)
z4
Use 2 sets of Height speakers in the appropriate sound modes for Dolby Atmos, DTS:X or Auro-3D playback.
Use the Front Height and Rear Height speakers for Dolby Atmos or DTS:X playback.
Use the Front Height and Surround Height speakers for Auro-3D playback.
z5 This can be set when “Assign Mode” in the menu is set to “13.1ch” or “11.1ch”, and “Floor” is set to “5ch” or “5ch & SB”. (v p. 240)
z6
This combination cannot be selected when Front Wide speakers are being used.
Contents
Connections Playback Settings Tips Appendix
245
Front panel Display Rear panel Remote Index

Denon AVR-X6700H Specifications

General

Channels	11.2
Power Output	140W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Speaker Impedance	4-16 ohms
Input Sensitivity/Impedance	200mV / 47k ohms
HDMI Inputs	8
HDMI Outputs	3
HDCP Support	HDCP 2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Video Upscaling	8K
Bluetooth	Yes
Wi-Fi	Yes
Ethernet	Yes
Voice Assistant Support	Amazon Alexa, Google Assistant, Apple Siri
Phono Input	Yes
Zone Audio Output	3 Zones
Room Calibration	Audyssey MultEQ XT32
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05%
Signal-to-Noise Ratio	102dB
HDMI Support	4K/120Hz, 8K/60Hz
USB Port	1
Streaming Services	AirPlay 2, HEOS, Spotify, Tidal, Deezer, Amazon Music, Pandora, SiriusXM
Audio Decoding	Dolby Atmos, DTS:X, Auro-3D
