42
END
Check PWM Audio Data output from PWM CONTROLLER.
MAIN B'D
[IC51] : 44,45,40,41pin
Check PWM Audio Data output for PWM CONTROLLER.
MAIN B'D
[IC71,IC72] : 14,16pin
Check Audio Data output from AMP to SPEAKER.
MAIN B'D
[IC71,IC72] : 22,25pin
[JK71]
Check Soldering.
[IC51] on MAIN B'D
Check Soldering.
[IC71,IC72] on MAIN B'D
Check Soldering.
[IC71,IC72] on MAIN B'D
[JK71] on MAIN B'D
NG
NG
NG
OK
OK
to 2.2. CD PLAY
z
Mark
2.3 . AM/FM TUNER-in
Check Power Supply Voltages for AM/FM TUNER.
MAIN B'D
[CN31] : 4pin +9V
[CN45] : 2pin +12V
Check Analog Audio Data output from TUNER PACK.
MAIN B'D
[TUNER PACK] output and [CN31]
: 7,5pin TUNER_L_IN, TUNER_R_IN
[IC41] : 59,60pin
Check Soldering.
[CN45] : 2pin +12V on MAIN B'D
SMPS B'D
Check Parts
[IC26]
Check Soldering.
[CN31]
: 7,5 pin TUNER_L_IN, TUNER_R_IN on MAIN B'D
[C426],[C427] on MAIN B'D
NG
NG
OK
OK
to 2.2. CD PLAY
z
Mark
2.4. Portable In
Check Audio Data input from DISPLAY B'D.
MAIN B'D
[IC41] : 61,62pin AUX1_L_IN, AUX1_R_IN
Check Analog Audio Signal from Portable In.
Portable In B'D
[Portable In] input
[BN81] : 1,3pin AUX_L_IN,AUX_R_IN
Check Soldering.
[JK83] on FRONT B'D
[BN81] on FRONT B'D
Check Soldering.
[CN44] : 1,3pin AUX1_L_IN, AUX1_R_IN
[C428], [C429] on MAIN B'D
NG
NG
OK
OK
