Denon RCD-N7 Service Manual

44
to 2.2. CD PLAY
z
Mark
2.7 . USB/iPod Dock/ETHERNET/WiFi
Check Power Supply Voltages for ETHERNET B'D.
ETHERNET B'D
• [CN25] : 1,2pin +6V
• [CN25] : 5,6pin +15V
Check Power Supply Voltages for USB.
ETHERNET B'D
• [CN21] : 1pin +5V
Check Power Supply Voltages for iPodDock.
ETHERNET B'D
• [CN22] : 1pin +5V
Check Power Supply Voltages for CR870.
ETHERNET B'D
• [IC24] : 5,6,7pin NET3.3V
• [IC23] : 5,6,7pin NET1.2V
• [CN26] : 3pin E_POWER_CONT "H" level O.K.?
Check Reset signal for ETHERNET B'D (CR870)
ETHERNET B'D
• [CN26] : 15pin E_RESET
"H" level O.K.?
Check Digital Audio Data for CODEC.
ETHERNET B'D
• [CN26] : 6pin 860_SPDIF
MAIN B'D
• [CN42] : 6pin 860_SPDIF
• [IC43] : 3,5pin 860_SPDIF
• [IC41] : 4pin 860_SPDIF
Check Soldering.
• [CN25] : 1,2pin +6V on ETHERNET B'D
• [CN25] : 5,6pin +15V on ETHERNET B'D
• [BN62] : 1,2pin +6V on MAIN B'D
• [BN62] : 5,6pin +15V on MAIN B'D
• [CN43] : 4pin +6V on MAIN B'D
• [CN45] : 9pin +15V on MAIN B'D
• SMPS B'D
Check Soldering.
• [CN21] : 1pin +5V on ETHERNET B'D
• [BN82] : 1pin +5V on DISPLAY B'D
• [JK81] on DISPLAY B'D
• [IC28] on ETHERNET B'D
Check Soldering.
• [CN22] : 1pin +5V on ETHERNET B'D
• [BN83] : 1pin +5V on iPodDock B'D
• [JK82] on iPodDock B'D
• [IC28] on ETHERNET B'D
Check Soldering.
• [IC24] on ETHERNET B'D
• [IC23] on ETHERNET B'D
• [CN26] : 3pin on ETHERNET B'D
Check Soldering.
• [CN26] : 15pin E_RESET on ETHERNET B'D
• [CN42] : 15pin E_RESET on MAIN B'D
• [IC11] : 127pin E_RESET on MAIN B'D
Check Soldering.
• [CN26] : 6pin 860_SPDIF on ETHERNET B'D
• [CN42] : 6pin 860_SPDIF on MAIN B'D
• [IC41] : 4pin 860_SPDIF on MAIN B'D
• [IC43] : on MAIN B'D
NG
NG
NG
NG
NG
NG
OK
OK
OK
OK
OK
OK

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
