Denon RCD-N7 Service Manual

75
R5F64169DFD(DISPLAY:IC81)TerminalFunction
PinNo PortName Symbol I/O Pull-U/D Note
1 P96/(TXD4) NC O - NC
2 (P95)/CLK4 NC O - NC
3
P94/(CTS4) NC O - NC
4
P93/(CTS3) NC O - NC
5 P92/TXD3 NC O - NC
6 P91/RXD3 NC O - NC
7 P90/(CLK3) NC O - NC
8
(P146)/INT8 NC O - NC
9
P145/INT7 NC O - NC
10
P144/INT6 NC O - NC
11 P143 NC O - NC
12 VDC0 VDC0 - - Smoothing capacitor connection terminal
13 P141(INPUT ONLY) NC I PD NC
14 VDC1 VDC1 - - Smoothing capacitor connection terminal
15 NSD NSD - PU Emulator communication pin
16 CNVSS(INPUT ONLY) CNVSS I PD
Single-chip / Micro-processor mode switching
(Normal single-chip : L, Rewrite boot program start : H input set)
17 P87/(XCIN) NC O - NC
18 P86/(XCOUT) NC I PD NC
19 RESET OLED_RESET I PU Reset input(Reset ="L")
20 XOUT X2 - - Clock output
21 VSS VSS - - GND
22 XIN X1 - - Clock input
23 VCC VCC1 - - +3V
24
P85/NMI NMI I PU NC
25
P84/INT2 NC O - NC
26
P83/INT1 YOBI O - Not use
27
P82/INT0 OLED_CS O - Chip Select of Display Data for Display ucom
28 P81 NC I PD NC
29 P80/RXD5 BOOT I PD Boot signal
30 (P77)/CLK5 NC O - NC
31 (P76)/TXD5 NC O - NC
32 P75/RXD8 OLED_POWER O PD OLED Power On/Off
33 P74/CLK8 NC O - NC
34 P73/TXD8 NC O - NC
35 P72/CLK2 OLED_CLK O - Clock of Display Data for Display ucom
36 P71/RXD2/(MSCL) OLED_TX O - Display Data for Display ucom
37 P70/TXD2/(MSDA) OLED_RX O - Not use
38 P67/TXD1 TXD CO O PD Data transfer to external terminal(AMX)/MITSUBISHI writer
39 VCC VCC1 - - +3V
40 P66/RXD1 RXD CO I PD Data received from the external terminal(AMX)/MITSUBISHI writer
41 VSS VSS - - GND
42 P65/CLK1/SCLK(L) SCLK_CO O PD Writing Mode Select
43 P64/BUSY BUSY_CO O - BUSY Output at updating
44 P63/TXD0 OLED_UART_RX O - Transfer Data for Display ucom at Updating
45 P62/RXD0 OLED_UART_TX I - Receive Data for Display ucom at Updating
46 P61/CLK0 NC O - NC
47
P60/CTS0 NC O - NC
48 P137 D7 O - Data Bus for OLED
49 P136/ISCLK2 D6 O - Data Bus for OLED
50 P135/ISRXD2 D5 O - Data Bus for OLED
51 P134/ISTXD2 D4 O - Data Bus for OLED
52
P57/RDY NC O - NC
53 P56/ALE NC O - NC
54
P55/HOLD/EPM EPM I PU Rewrite boot program start : L input set
55
P54/HLDA NC O - NC
56 P133 D3 O - Data Bus for OLED
57 VSS VSS - - GND
58 P132 D2 O - Data Bus for OLED
59 VCC VCC2 - - +3V
60 P131 D1 O - Data Bus for OLED
61 P130 D0 O - Data Bus for OLED
62 P53/BCLK NC O - NC
63
P52/RD NC I PD NC
64
P51/(WR1)/BC1 NC O - NC

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
