Denon RCD-N7 Service Manual

76
PinNo PortName Symbol I/O Pull-U/D Note
65
P50/(WR0)/WR/CE CE_M I PD Rewrite boot program start : H input set
66 P127 RES# O - Reset, Active "L" for OLED
67 P126 CS# O - Chip Select for OLED
68 P125 D/C# O - Data/Command Control. "H" :Data, "L":Command for OLED
69
P47/CS0/(A23) R/W#,WR# O - Write (This pin stays "L"(low) in Serial Interface Mode) for OLED
70
P46/(CS1)/A22 E,RD# O - Read (This pin stays "L"(low) in Serial Interface Mode) for OLED
71
P45/(CS2)/A21 NC O - NC
72
P44/(CS3)/A20 NC O - NC
73 P43/A19 NC O - NC
74 VCC VCC - - +3V
75 P42/A18 NC O - NC
76 VSS VSS - - GND
77 P41/A17 NC O - NC
78 P40/A16 NC O - NC
79 P37/A15 NC O - NC
80 P36/A14 NC O - NC
81 P35/A13 NC O - NC
82 P34/A12 NC O - NC
83 P33/A11 NC O - NC
84 P32/A10 NC O - NC
85 P31/A9 NC O - NC
86 P124 NC O - NC
87 P123 NC O - NC
88 P122/(RXD6) NC O - NC
89 P121/(CLK6) NC O - NC
90 P120/(TXD6) NC O - NC
91 VCC VCC - - +3V
92 P30/A8 NC O - NC
93 VSS VSS - - GND
94
P27/A7 NC O - NC
95 P26/A6 NC O - NC
96 P25/A5 NC O - NC
97 P24/A4 NC O - NC
98 P23/A3 NC O - NC
99 P22/A2 NC O - NC
100 P21/A1 NC O - NC
101 P20/A0 NC O - NC
102 P17/D15 NC O - NC
103 P16/D14 NC O - NC
104 P15/D13 NC O - NC
105 P14/D12 NC O - NC
106 P13/D11 NC O - NC
107 P12/D10 NC O - NC
108 P11/D9 NC O - NC
109 P10/D8 NC O - NC
110 P07/D7 NC O - NC
111 P06/D6 NC O - NC
112 P05/D5 NC O - NC
113 P04/D4 NC O - NC
114 P114 NC O - NC
115 P113 NC O - NC
116 P112/(RXD8) NC
O - NC
117 P111/ NC O - NC
118 P110/(TXD8) NC O - NC
119 P03/D3 NC O - NC
120 P02/D2 NC O - NC
121 P01/D1 NC O - NC
122 P00/D0 NC O - NC
123 P157 NC O - NC
124 P156 NC O - NC
125 P155/RXD6 NC O - NC
126 P154/TXD6 NC O - NC
127 P153 NC O - NC
128 P152/RXD7 NC O - NC
129 P151/(CLK7) NC O - NC
130 VSS VSS - - GND
131 P150/TXD7 NC O - NC

Denon RCD-N7 Specifications

General

Frequency range	5 - 20000 Hz
RMS rated power	65 W
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Dynamic power per channel (4 Ohm)	80 W
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	1
Headphone connectivity	3.5 mm
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Image formats supported	JPG
Video formats supported	AVI, WMV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	99
Internet radio services supported	Last.fm, Napster
Optical drive type	CD player
Disc types supported	CD, CD-R, CD-RW
Display	OLED
Product color	Silver
Audio decoders	Not supported
Volume control	Rotary
Apple docking compatibility	iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4300 g
