6159924940 - 07/2020 - 13 -
The torque is below the minimum torque.
The torque is above the maximum torque.
The angle is below the minimum angle.
The angle is above the maximum angle.
The torque is in the tolerance of the target torque.
The angle is in the tolerance of the target angle.
The torque is above the assembly torque limit.
The angle is above the assembly angle limit.
Table3: Trend
Viewing other results
Go to this menu.
Press this icon to view the last result.
Use the Up and Down keys to change the display.
Use Left or Right keys to select another result.
Keep pressing the key to display the results by 10.
This screen indicates that a run reverse operation has been
done.
Getting results full screen
The Zoom mode is used to display the Torque or Angle or Report full screen.
When this mode is activated, the last result and the selected Pset are alternatively displayed.
If any key is pressed, the zoom is removed and the default configuration is displayed.
Go to this menu.
Press this icon up to Service / Zoom disabled.
Use Left or Right keys to change your selection.
Press this icon validate your selection.
