82
PBX Networking PBX Networking
group configuration for the routes to
be reseized.
Tip: If, for example, you are config-
uring a route which can be seized us-
ing routing code “5” and have se-
lected one or more bundles for this
route, change the Prefix for dest.
call number at incoming internal
setting to “5” for this bundle in order
to enable the route to be reseized.
Owing to their hardware properties,
not all S
0
ports of the OpenCom 100
can be used for PBX networking
without restrictions. Depending on
the type of system, some ports can
only operate in the L1 master mode
or L1 slave mode. The external S
0
and S
2M
ports can be set according
to the following table.
Legend
S = Slave
M/S = Master/Slave
M = Master
S
0
1S
0
2S
0
3S
0
4S
0
5S
0
6S
2M
OpenCom 105 S M/S M/S M – – –
OpenCom110SSM/SM/SM––
OpenCom120 M/SM/SM/SM/SM/SM/SM/S
