3.2.11 DEV 13-0063
1:4/4:1 Splitter/Combiner Module, Passive; 950…2150 MHz; 75 Ohm, F (f)
1
5
4
In
Out 1
Out 2
Out 3
Out 4
3
2
DE V 13-0063
Ou t 1
Ou t 2
In
Ou t 3
Ou t 4
This passive module for splitting or for combining RF signals can be installed in a
DEV 1953 as a supplemental module.
3.2.12 DEV 13-0235
1:4/4:1 Splitter/Combiner Module, Passive; 47…1006 MHz; 75 Ohm, F (f)
1
5
4
In
Out 1
Out 2
Out 3
Out 4
3
2
DE V 13-0235
Ou t 1
Ou t 2
In
Ou t 3
Ou t 4
This passive module for splitting or for combining RF signals can be installed in a
DEV 1953 as a supplemental module.
