Replacing Consumables 11-25
7 Push down the guides.
8 Hold the handles, and then care-
fully pull out the transfer belt
unit.
" Be sure to keep the
transfer belt level; other-
wise, the transfer belt
may be scratched.
9 Prepare a new transfer belt unit.
" Be careful not to touch
the surface of the belt.
" Do not remove the blue
lever.
To Next Page
