Step 6: Throttle Setup
The Throttle uses a complex mixer in order to support the throttle-hold. When THOLD
is enabled, the throttle will cut to zero, but the Collective will continue to function.
Page 1 2 3 4
# Mixers 1
Switch None FMODE1 FMODE2 GEAR
Src THR
Curve 5pt: -100,-
20,30,70,90
5pt: 80, 70, 60,
70, 100
5pt: 100, 90, 80,
90, 100
Fixed
Scale 100 -100
Offset 0
Trim Enabled
