Dexter Laundry V-Series User Manual

Cabinet and Front Panel Group Part # by Model Continued
Key Part Number
13 9244-081-001
13 9244-081-002
13 9244-081-003
* 9545-045-010
* 9545-008-023
14 9545-008-014
14 8641-585-001
* 8640-399-008
15 9108-095-005
* 9451-191-001
* 9467-025-001
* 9545-045-002
* 9545-008-012
* 8640-399-007
* 9086-017-001
22 9467-024-001
* 8640-411-003
23 9355-001-001
24 9545-008-025
16 9732-122-001
17 9021-001-001
18 9456-041-007
20 9539-461-007
21 9950-060-001
21 9950-059-001
21 9950-060-002
* Not Illustrated
Description .................................................................................Qty
Handle (bumper guard) WCVD-18.....................................................1
Handle (bumper guard) WCVD-40, WCVD-25....................................1
Handle (bumper guard) WCVD-55,WCVD-75.....................................1
Screw.............................................................................................4
Screw, Guide...................................................................................2
Screw Mtg., Flat Head.....................................................................2
Washer, Finish.................................................................................2
Nut, Spring.....................................................................................2
Door, Dispenser WCVD-18,WCVD-25,WCVD-40,WCVD-55...................1
Pin, PlainWCVD-18,WCVD-25,WCVD-40,WCVD-55.............................2
Post, Door MountingWCVD-18,WCVD-25,WCVD-40,WCVD-55.............2
Screw, Disp.Post MtgWCVD-18,WCVD-25,WCVD-40,WCVD-55............4
Screw, Disp. Mtg. WCVD-18,WCVD-25,WCVD-40,WCVD-55................4
Nuts, Spring WCVD-18,WCVD-25,WCVD-40,WCVD-55........................4
Catch, Top Panel..............................................................................2
Post, Top Locator.............................................................................2
Nut, Keps.......................................................................................2
Locator, Panel..................................................................................2
Screw, #10.....................................................................................2
SS cover Box Assy, Coin (See Coin Handling Group)...........................1
Acceptor, Coin ($.25) (See Coin Handling Group)...............................1
Plastic Plug 1 1/2”-(inside cylinder) WCVD-18,WCVD-25,WCVD-40......1
Switch Coin Blocking Safety..............................................................1
Masking Ring with saftey switch opening WCVD25,40,55...................1
Masking ring with saftey switch opening WCVD-18............................1
Masking Ring with saftey switch opening WCVD-75...........................1
98 99
Part # 8533-050-001 2/22 Part # 8533-050-001 2/22
Notes
98
Machine
Mounting
Installation
& Operation
Programming
Trouble-
shooting
Machine
Service
Electrical
Wiring
Parts
Data
Coin
Handling
Maintenance
Service Elec.
Compnents
Control
Panel
Electrical
Components
Water Inlet &
Rear Channel
Chassis
& Drain
Loading
Door
Door
Lock
Cylinder, Seals,
& Bearings
Rear
View
Cabinet &
Front Panel
Wiring
Harnesses
Kits &
Assemblies
Accessories
