Digi ConnectCore Hardware Reference Manual

About the module Module pinout
ConnectCore for i.MX51 Hardware Reference Manual
28
Pin Type Signal name Use on module
Use on
development
board
Comments
J2:1 HSGPIO27 DISP1_DAT0 i.MX51: DISP1_
DAT0
HDMI, VGA
and LCD1
Data
On the Development
Kit, DISP1 and DISP2
are configured at 18-
bit, and connected
to 24-bit LCDs.
On the Development
Kit, some DISP1
signals are used to
configure the boot
process.
On the Early
Availability Kit,
DISP1 and DISP2 are
configured at 24-bit,
and connected to
24-bit LCDs.
J2:2 HSGPIO27 DISP1_DAT1 i.MX51: DISP1_
DAT1
HDMI, VGA
and LCD1
Data
J2:3 HSGPIO27 DISP1_DAT2 i.MX51: DISP1_
DAT2
HDMI, VGA
and LCD1
Data
J2:4 HSGPIO27 DISP1_DAT3 i.MX51: DISP1_
DAT3
HDMI, VGA
and LCD1
Data
J2:5 HSGPIO27 DISP1_DAT4 i.MX51: DISP1_
DAT4
HDMI, VGA
and LCD1
Data
J2:6 HSGPIO27 DISP1_DAT5 i.MX51: DISP1_
DAT5
HDMI, VGA
and LCD1
Data
J2:7 GPIO27 DISP1_DAT6 i.MX51: DISP1_
DAT6
HDMI, VGA
and LCD1
Data, Boot
Configuration
J2:8 GPIO27 DISP1_DAT7 i.MX51: DISP1_
DAT7
HDMI, VGA
and LCD1
Data, Boot
Configuration
J2:9 GPIO27 DISP1_DAT8 i.MX51: DISP1_
DAT8
HDMI, VGA
and LCD1
Data, Boot
Configuration
J2:10 GPIO27 DISP1_DAT9 i.MX51: DISP1_
DAT9
HDMI, VGA
and LCD1
Data, Boot
Configuration
J2:11 GPIO27 DISP1_DAT10 i.MX51: DISP1_
DAT10
HDMI, VGA
and LCD1
Data, Boot
Configuration
