About the module Module pinout
ConnectCore for i.MX51 Hardware Reference Manual
31
Pin Type Signal name Use on module
Use on
development
board
Comments
J2:38 GPIO27 DI1_D0_
CS/GPIO3_3
i.MX51: DI_D0_CS LCD1 and
LCD2 Touch
selection
input
J2:39 ADIN TOUCH_X1 MC13892: TSX1 LCD1 and
LCD2 Touch
X1
Analog input from
Touch Screen
J2:40 ADIN ADIN5 MC13892: ADIN5 Reserved
J2:41 ADIN TOUCH_X2 MC13892: TSX2 LCD1 and
LCD2 Touch
X2
Analog input from
Touch Screen
J2:42 ADIN ADIN6 MC13892: ADIN6 Not used Analog input
J2:43 ADIN TOUCH_Y1 MC13892: TSY1 LCD1 and
LCD2 Touch
Y1
Analog input from
Touch Screen
J2:44 ADIN ADIN7 MC13892: ADIN7 Not used Analog input
J2:45 ADIN TOUCH_Y2 MC13892: TSY2 LCD1 and
LCD2 Touch
Y2
Analog input from
Touch Screen
J2:46 - ADC_GND - -
J2:47 - GND - -
J2:48 PMIC_
STDBY
ADTRIG MC13892: ADTRIG Not used
J2:49 - SWBST MC13892: SWBST
MC13892: VINUSB
- Used on the module
to power USB PHY
J2:50 - LEDKP MC13892: LEDKP Reserved
J2:51 PMIC_LED LEDR MC13892: LEDR Not used
J2:52 - LEDAD MC13892: LEDAD Reserved
J2:53 PMIC_LED LEDG MC13892: LEDG Not used
J2:54 - LEDMD MC13892: LEDMD Reserved
J2:55 PMIC_LED LEDB MC13892: LEDB Not used
J2:56 - VSWLED - -
J2:57 GPIO27 CSI2_D12/GPIO4_9 i.MX51: CSI2_D12 Camera 2
Data
