This screen lists the detonators that were found to be bad during the test. (A bad status indicates the detonator
may have a bad fuse or other internal problem).
1. Main Menu
• Press Key to select View Design.
2. View Design
• Press Key to select List Bad Status Detonators.
3. List Bad Status
• The List Bad Status screen will be displayed
• Use SoftKeys to navigate pages and sort/filter the view as required.
• X indicates Bad status detonators
• D indicates duplicate detonators
This List does NOT include untagged detonators.
Failures may be the result of cable damage, connector or other problems.
A bad status detonator must be replaced even if subsequent test results indicate good.
