DigiShot plus.4G - Leakage Trigger; Blasting Method (Base Station)

UTM-00339 | Rev 19
Page 210 of 253
DetNet South Africa Copyright © 2021
1. Configuration Menu
• Press to select 4G Setup
• Press to select Leakage Trigger
2. Leakage Trigger
• Select leakage warning trigger level using numerical keys
to move up or down (0.5mA to 5.0mA)
• Press Softkey to save
Blasting Method Configuration is only available on the Base Station. This setup allows the user to enforce
synchronized blasting when conducting remote blasting with more than one Bench Commander by selecting Sync
only in the blasting method configuration. This setup also allows the user to select between non- synchronized
blasting or synchronized blasting by configuring the blasting method to Sync and Non-Sync.
1. Configuration Menu
• Press to select 4G Setup
• Press to select Blasting Method
2. Blasting Method
• Use numerical keys to toggle between Sync and
Non-Sync or Sync only
• Press Softkey to save
