D4204-EN Scale Link 2 Technical Manual 13
Small box, quad platform M12 EZMate scale (410624 SL2140 shown)
Accessory port for
options such as remote
input & output control
ISOBUS/ CAN port for
power and primary
communication
Scale A
4 bars
Scale B
4 bars
Scale C
4 bars
Scale D
4 bars
SLC remote
& Serial Ports
M12 jumper cables
are used between
SL2 and J-blocks
