Digistar SCALE LINK SL2 - Page 14

14 Scale Link 2 Technical Manual D4204-EN
Large box, dual platform 8 Terminal Block scale (410619 SL2220 shown)
ISOBUS/ CAN port for
power and primary
communication
SLC Remote
& Serial Port
Scale A
4 bars
Scale B
4 bars
Single scale models: All 8 terminal
connections are SCALE A
Dual-scale models (as shown): Each 4
terminal section is a different scale; A & B
