D4204-EN Scale Link 2 Technical Manual 15
More system configurations and options are available. Complete systems are configured based on similar box
designs below. Mounting brackets are available for easier installation. Contact Topcon for more details.
Small Box designs
M12 or strain reliefs/ direct wire
Single scale or up to 4 platforms
Up to 4 load cell connections
With or without cables and
connectors
Large Box designs
Strain reliefs/ direct wire
Single scale or Dual scale
Up to 10 load cell connections
