D4204-EN Scale Link 2 Technical Manual 51
SAVTAR (D.A.N. 7117) SAVE TARE
ON = Indicator will save tare weight to non-volatile memory.
WT COM (D.A.N. 7118) WEIGHT COMPENSATION
Enables weight compensation functionality for scale platform A
AD FLT (D.A.N. 7119) AD FFT FILTERING
Enables A/D FFT filtering for scale platform A
CAL100 (D.A.N. 7121) FRACTIONAL WEIGHT CALIBRATION
Enables use of fractional CAL numbers for scale platform A
GAIN (D.A.N. 7122) GAIN
Select gain setting to be used for scale platform. (.75mv/v, 1.5mv/v, 3mv/v)
SCALE PLATFORM B
SCALID (D.A.N. 7151) SCALE ID SETUP
Identity of scale location (Truck ID or Mixer Number).
W MTHD (D.A.N. 7153) WEIGH METHOD
Select weigh method 1-General, 2-Slow, 3-Fast, or 4-Lock - On (Stockweigh only)
LB-KG (D.A.N. 7154) DISPLAY UNIT
Display pounds - lb or kilograms – kg
COUNT (D.A.N. 7155) DISPLAY COUNT
Select display count size of weigh values.
CAP (D.A.N. 7156) CAPCITY
Enter MAXIMUM weight measurable on scale.
WMA1-1 (D.A.N. 7157) WM1 ADJUST 1
Increase this number to smoothen weighing (2 to 100)
WMA1-2 (D.A.N. 7158) WM1 ADJUST 2
0=OFF. Use value less than WMA1-1 for quick weight response.
WMA1-3 (D.A.N. 7159) WM1 ADJUST 3
Enter the weight to activate quick weight response.
WMA2-1 (D.A.N. 7161) WM2 ADJUST 1
Increase this number to smoothen weighing.
