Quick Start
For those of you who prefer to burn now and read later, we've included this Quick Start section to get you up and running.
Connect Cables:
Connect guitar into the Input jack (located on the rear of the RP-20). Now run from the Output of the RP-20 to the Input of the either the
Guitar Amp, Power Amp or Mixing board.
Apply Power:
Note: When applying power to the RP-20 Valve, it is recommended that the <Input> and <Output> be turned down prior to powering up
the unit.
Adjust Input and Output:
Use the <Input> level knob on the rear panel to adjust the Input level, so that the loudest guitar signal occasionally lights the clip LED
indicator. Now adjust the <Output > level knob on the rear panel of the RP-20 Valve to the desired output level .
Select Preset:
Begin playing your guitar, and choose any preset using the <Data> wheel or pressing any one of the ten footswitches. User Presets 1-100 are
duplicates of the Factory Presets. They are user-programmable. You can modify and store them as you want. Factory Presets 1-100 are not user-
programmable and cannot be overwritten.
