REQUEST ONE PROGRAM (01h)
SYS_HEAD, 01(h), yy1, yy2, zz1, zz2 F7(h)
When yy = 00(h) User bank is selected
When yy = 01(h) Factory bank is selected
zz The Program number, 1-100 User (00-63(h)) or 1-100 Factory (00-63(h))
When a Request One Program procedure is received, the RP-20 Valve will respond with a Receive One Program procedure.
RECEIVE ONE PROGRAM (42h)
SYS_HEAD 42(h), vv(1)1, vv(1)2, vv(2)1, vv(2)2, yy1, yy2, zz1, zz2, dd(1st)1,dd(1st)2, ... dd(nth)1, dd(nth)2, F7(h)
vv software version number
When yy = 00(h) User bank is selected
When yy = 01(h) Factory bank is selected
zz The Program number, 1-100 (00-63h)
dd(n) Program data
The Receive One Program procedure is used to load a program into the RP-20 Valve. The number of program bytes to be received (n) is
different for each program. If the RP-20 Valve is sent a Receive One Program procedure where the program number is not a valid RAM
destination, it will be ignored.
REQUEST BULK DUMP (49h)
SYS_HEAD, 49(h), F7(h)
When a Request Bulk Dump procedure is received, the RP-20 Valve will respond with a Receive Bulk Dump procedure.
RECEIVE BULK DUMP (48h)
SYS_HEAD 48(h), dd(1st)1 dd(1st)2, ... dd(nth)1, dd(nth)2, F7(h)
dd(n) Bulk Dump Data
The Receive Bulk Dump procedure is used to load all User Programs into the RP-20 Valve. A software version number is imbedded in the data.
REQUEST UTILITY SETTINGS (11h)
SYS_HEAD, 11(h), F7(h)
When a Request Utility Settings procedure is received, the RP-20 Valve will respond with a Receive Utility Settings procedure.
Section - 6 Appendix
RP-20 Valkve
User Guide
82
