RECEIVE UTILITY SETTINGS (12h)
SYS_HEAD 12(h), vv(1)1, vv(1)2, vv(2)1, vv(2)2, rr1, rr2, tt1, tt2, ee1, ee2, ff1, ff2, ss1, ss2, nn1, nn2, mm1,
mm2, qq1, qq2, yy (1st)1,yy(1st)2, zz(1st)1,zz(1st)2 ... yy(128th)1,yy(128th)2, zz(128th)1,zz(128th)2, F7(h)
vv = software version number
rr = MIDI Receive Channel (range = 00(h) ~ 07(h))
tt = MIDI Transmit Channel (range = 00(h) ~ 07 (h)
ee = Cabinet Emulator (range = 00(h) ~ 07 (h)
ff = Foot Controller (range = 00(h) ~ 07(h))
ss = SysEx Channel (Millennium only)
nn MIDI Merge On/Off (RP-20 Valve only)
mm Mono-Stereo (range = 00(h) ~ 01(h)
qq EQ mode (range = 00(h) ~ 07(h))
yy, zz Program Map Settings (MIDI Program changes 1 ~ 128 = map)
When yy = 00(h) User Bank is selected
When yy = 01(h) Factory Bank is selected
When yy = 02(h) and zz =00(h), Bypass toggle is selected
zz Program Number.
REQUEST PARAMETER VALUE (17h)
SYS_HEAD 17(h), aa1, aa2,bb's1, bb's2, F7(h)
aa Effect Module’s Position
bb's Effect Parameter’s Position
When a Request Parameter Value procedure is received, the RP-20 Valve will respond with a Receive Parameter Value procedure.
RECEIVE PARAMETER VALUE (18h)
SYS_HEAD 18(h), aa1,aa2, bb's1, bb's2,cc1, cc2, F7(h)
aa Effect Module’s Position
bb's Effect Parameter’s Position
cc Parameter Value
The Receive Parameter Value procedure is used to load Parameter Values into the RP-20 Valve. Please refer to the Parameter Charts for more
information.
REQUEST ALL CURRENT PARAMETER VALUES (23h)
SYS_HEAD, 23(h), ww1, ww2, F7(h)
RP-20 Valve
User Guide
Section - 6 Appendix
83
