100
Remote IP Specify the remote (destination) IP address
Address: (e): that will be affected by this rule. Please input the
starting IP address in the left field, and input the end IP
address in the right field to define a range of IP
addresses, or just input the IP address in the left field to
define a single IP address.
Remote Port Please input the range of remote (destination)
Range (f): port number that will be affected by this rule. If you want
to apply this rule on port 80 to 90, please input ’80-90’; if
you want to apply this rule on a single port, just input
the port number, like ‘80’. If the remote (destination) IP
address and /or port number is universal, just leave it
blank.
Traffic Type (g): Please select the traffic type of this rule,
available options are None, SMTP, HTTP, POP3, and
FTP. You can select a specific traffic type for this rule, if
you want to make this rule as a IP address based rule
(apply the limitation on all traffics from / to the specified
IP address / port number), select ‘None’.
Protocol (h): Please select the protocol type of this rule,
available options are TCP and UDP. If you don’t know
what protocol your application uses, please try ‘TCP’
first, and switch to ‘UDP’ if this rule doesn’t seems to
work.
After you finish with all settings, please click ‘save’ button (i), you’ll be brought
back to previous menu, and the rule you just set will appear in current QoS
table; if you did anything wrong, you’ll get an error message when you click
‘Save’ button, please correct your input by the instructions given by the error
message.
If you want to erase all values you just entered. Click ‘Reset’
