Here are descriptions of every setup items:
Enable Virtual Check this box to enable virtual server,
Server (1): and uncheck this box to disable virtual server.
Private IP (2): Input the IP address of the computer which
provides Internet service.
Computer Name (3): Pull down the menu and all the computers connected to
the router will be listed here. You can easily to select
the computer name without checking the IP address of
the computer.
Private Port (4): Input the port number of the IP address
which provides Internet service.
Type (5): Select the type of connection, TCP or UDP. If you’re not
sure, please select ‘Both’.
Public Port (6): Please select the port number of Internet IP address
which will be redirected to the port number of local IP
address defined above.
Comment (7): Please input any text to describe this mapping, up to 16
alphanumerical characters.
Add (8): Add the mapping to virtual server table.
Reset (9): Remove all inputted values.
Virtual Server All existing virtual server mappings will be
Table (10): displayed here.
Delete (11): Please select a virtual server mapping by clicking
the ‘Select’ box of the mapping, then click ‘Delete
Selected’ button to remove the mapping. If there’s no
existing mapping, this button will be grayed out.
Delete All (12): Delete all mappings existed in virtual server table.
Reset (13): Unselect all mappings.
