Connecting Your HDTV Monitor
Connect Your DISH Network Satellite Receiver
1. Connect a DVI cable between the monitor and DISH Network satellite
receiver
DISH DVI connectors.
2. Connect red and white RCA-type cables between the matching color
RCA-type plugs on the monitor audio inputs and DISH Network
satellite receiver audio outputs.
Connect a VCR (Optional)
Follow these instructions to connect the monitor to a VCR. See your VCR
User’s Guide for VCR setup instructions.
1. Connect yellow, white, and red RCA-type cables between the matching
color RCA-type plugs at
VID1 or VID2 inputs on the monitor and the
VCR outputs.
2. Connect yellow, white, and red RCA-type cables between the matching
color RCA-type plugs at the inputs on the VCR and the satellite TV
receiver outputs.
Note: Optionally, instead of connecting video using yellow RCA-type
connections, connect an S-Video cable at the input on the VCR and
satellite TV receiver output.
Follow these instructions to connect the monitor to a DVD player or other
device. See your DVD player or other device User’s Guide for setup
instructions.
1. Connect green, blue, and red
Y-P
B
-P
R
cables between the matching
color connections at
CMP1 or CMP2 inputs on the monitor and outputs
on a DVD player or other device.
2. Connect white and red RCA-type cables between the matching color
RCA-type plugs at
CMP1 or CMP2 inputs on the monitor and the
outputs on a DVD player or other device.
Plug In Your Monitor to a Power Outlet
Connect a DVD Player and/or Game Console
(Optional)
