Chapter 3
Page 32
Using the Monitor’s Features
FRNT - The device is connected to the VIDEO jack on the front of the
monitor and you want the monitor to tune to the front
VIDEO input
channel (
FRNT) when you press the corresponding button.
CMP1 or CMP2 - The device is connected to the CMP1 or CMP2
component jacks on the back of the monitor an you want the monitor to
tune to a component input channel when you press the corresponding
button.
DVI - A DISH DVI-equipped DISH Network satellite receiver is
connected to the
DISH DVI input on the back of the monitor and you
want the monitor to tune to the
DISH DVI channel when you press the
corresponding button.
Convergence (Projection Models Only)
Auto Convergence
Auto Convergence automatically adjusts the monitor’s tubes to make a
clear picture on the screen. You should perform auto convergence when you
install, move or rotate your monitor. For best results, make sure the monitor
has been on for about an hour when you perform the auto-convergence
procedure.
There are two adjustments made when you use auto convergence:
•
Red convergence displays the Red convergence screen, allowing
you to use the arrow buttons to align the red and green images.
•
Blue convergence displays the Blue convergence screen, allowing
you to use the arrow buttons to align the blue and green images.
Your monitor’s picture tubes might have been disturbed during delivery or
after you moved the monitor, causing the color in your monitor to be out of
alignment. The colors adjust by starting auto convergence.
Note: To converge the monitor’s DISH DVI picture, you must have the
monitor switched to the DISH DVI input during convergence. To converge
on standard definition inputs, repeat auto convergence on one of those
inputs.
1. Press MENU and select
Convergence.
2. Select
Auto Convergence.
3. When the auto convergence is complete, the
Red Center Convergence
screen appears. The cross in the middle of the screen should be
completely yellow. If it is not, use the ARROW buttons to move the red
cross to overlap the green cross. Press SELECT/OK when the cross is
completely yellow.
4. The
Blue Center Convergence screen appears with a completely cyan
(blue-green) cross in the middle of the screen. If it is not, use the
ARROW buttons to move the blue cross to overlap the green cross.
Press SELECT/OK when the cross is completely cyan (the monitor
tunes to the last available channel in the channel list).
