C16x/C24x/C30x Operator’s Manual Service - 103
As Needed
Connect Batteries
1. Connect red positive (+) cable clamp to positive (+) post (2) of defective battery.
2. Connect other red positive (+) cable clamp to positive (+) post of service vehicle battery.
3. Connect black negative (-) cable clamp to negative (-) post of service vehicle battery.
4. Connect other black negative (-) cable clamp to engine or frame ground on defective equipment, at
least 12” (305 mm) from defective battery.
Charge Defective Battery
1. Operate service vehicle engine at 1500-2000 rpm for a few minutes.
2. Stop engine in service vehicle.
Disconnect Batteries
1. Remove black negative (-) clamp from negative post of service vehicle battery.
2. Remove black negative (-) clamp from engine or frame ground of defective machine.
3. Remove red positive (+) clamp from positive post of service vehicle battery.
4. Remove red positive (+) clamp from external positive terminal (1) or internal positive post (2) of
defective battery.
5. Reconnect machine controller and try to start defective machine.
6. If defective machine does not start, replace battery.
IMPORTANT: Some machines have an external positive terminal (1). In that case, connect positive
clamp to external terminal.
