RT45 Operator’s Manual Controls - 49
Right Fender
2. Level control To lower rear of
microtrencher, push.
To raise rear of microtrencher,
pull.
3. Lift control To lower, push.
To raise, pull.
4. Backfill blade tilt /
Traverse selector
To control backfill blade tilt,
push.
To control microtrencher
traverse, pull.
Use when optional 6-way backfill
blade is installed.
Item Description Notes
