DoAll C-4033NC - Machine Preparation

 26

SETUPFORCREATINGJOBS(Continued…)
10. InautomaticmodewhentheCOUNTquantity
reaches the programmed QTY, the machine will
automaticallyperformthenextjobtobeexecuted
untilalljobsaredone.

MACHINEPREPARATION
Sawbandrecommendations
1. A high‐speed DoALL Silencer PLUS saw band is
suppliedwiththemachine.Bandlength,widthand
recommended gage depends on machine model
(seemachinespecificationschart).
2. A machine in correct adjustment, good operating
conditionandusingpropercuttingfluidisessential
toefficientsawing.
3. Properbladecareshouldinclude:(a)pushinguncut
stock away from the band and lowering the saw
headif the machineis to remain idlefor alonger
period;(b)usingcorrectbandspeed,feedforceand
cuttingfluids duringoperation; (c)removing scale
fromstockbeforesawing.

Bladeguards

1. Themachinehastwo(2)bladecoveringguardsfor
operatorsafety.Allguardsmustbeinplacebefore
anysawingprocedureisstarted.
 Left guard. This guard is attached to the left
sawguide armand extendstowardsthe idler
bandwheel.
 Right guard. Thisguard extends betweenthe
rightsawguidearmandthedrivebandwheel.
This isa fixed, integral part ofthe right band
wheeldoor.
DO NOT defeat their purpose by operating
themachinewithouttheseguardsattached.
THEYARETHEREFORYOURPROTECTION!

Sawguideinsertadjustment
1. Oneachsawguidearmloosentheadjustment
screw by turning it counterclockwise. Then: (a)
checkthatthesawbandisupagainsttheback‐up
insert; (b) turn the insert adjustment screw
clockwiseuntiltight,thenbackoff1/4turn.

Sawbandremoval
Always use extreme care when handling saw
bands.Weargloves.

1. TurnthebanddrivemotortoOFFandthenpushthe
hydraulicstartbutton.Then:(a)pushandholdthe
sawheadupbuttonandallowtheheadtorisetoits
maximumheight;(b)turnthebandtensionselector
toOFF(thismovestheidlerbandwheeltotheright).
2. Openbothbandwheeldoorsuntiltheyengageand
stayopen.Then:(a)loosentheclamphandleonthe
band brush; (b) push the band brush down away
fromthebladeteeth.
3. Loosenthesawguideinsertsonbothsawguide
arms by turning each adjustment screw
counterclockwise(donotallowtheinsertstofall
out). Next:(a) loosen the left saw guide arm lock
handle;(b)sidethe leftsawguidearmabout250
mmfromtherightsawguidearm.
4. Placeaglovedhandonthebackofthesawband
portionbetweenthesawguidearms:(a)pushthe
saw band downand out to disengage it from the
saw guide inserts (you will want to grip the saw
bandfirmlyasyoumanipulateit);(b)removethe
sawbandfromaroundthebandwheels,thenfrom
thetopchannel.
5. Maneuverthedrivebandwheelendloopofthesaw
bandoutwardandtotherightwhilemaneuvering
the idler band wheel end loop between the idler
bandwheelandtheleftsawbandguard.Then:(a)
manipulate the top part of the saw band out
betweentherightsawbandarmandtheband
brushdeflectorshield;(b)recoilthesawbandand
storeordisposeofitimmediately.

Sawbandinstallation
Always use extreme care when handling saw
bands.Weargloves.

1. Carefullyfollowall sawbandremovalprocedures.
Use the flushing hose to clean areas around saw
guidesandinserts,plusbothbandwheels.
2. Slip the saw band under both saw guide arms by
followingthereverseprocedureofstep4inthesaw
removal section. Then: (a) position the saw band
aroundbothbandwheels.
3. Slipthetopportionofthesawbandloopintothe
topchannel.Then:(a)graspthesawbandportion
betweenboth saw guidearms andtwist it so the
teeth are pointing down; (b) slip the twisted saw
bandupbetweenthesawguideinserts.


