4
MACHINE DIMENSIONS
INSTALLATION DIMENSIONS
Dimensions
C-3028NC C-4033NC C-420NC C-5650NC C-560NC C-6260NC
A
2.750 mm 2.980 mm 2.980 mm 3.000 mm 2.850 mm 2850 mm
B
600 mm 600 mm 600 mm 600 mm 600 mm 600 mm
C
3.160 mm 3.420 mm 3.680 mm 3.980 mm 4.760 mm 4700 mm
D
1.060 mm 1.170 mm 1.265 mm 1.370 mm 1.600 mm 1600 mm
E
950 mm 1.050 mm 1.150 mm 1.250 mm 1.450 mm 1450 mm
