Output Module Communication
Error
I/O module communication issue with
the PC.
1. Refer to I/O
Verification
Procedure
96149
Timeout Advancing Parallel
Analyzers
Tape advance issue in parallel analysis
mode.
1. Reset fault and re-
enter analysis
2. If fault reoccurs
contact DOD
Technologies, Inc.
Critical
Fault
CL96 System Fan Failure
Fan on side panel has failed
1. Replace fan on
CL96 side panel
Critical
Fault
Pyrolyzer Control Module Fault
Communication issue between the PC
and pyrolyzer control modules
1. Verify connection
of communication
modules. 2. Unplug
and re-insert cables
on communication
module 3. power
cycle CL96 4. Replace
communication
modules
96114
Low Flow
A point has a flow value below the
required amount of flow
1. Refer to Flow Path
Verification
Procedure
96115
High Flow
A point has a flow value above the
required amount of flow
1. Refer to Flow Path
Verification
Procedure
96120
Idle Timeout (Analyzer)
An analyzer was left out of analysis for a
time frame that overlapped the time
out setting
1. Check to see if a
fault caused the CL96
to leave analysis
2. If not put the CL96
back into analysis
96124
ChemLogic tape low
The tape counter days remaining value
is equal to the warning value setting
1. Replace the
Chemlogic cassette
2. Reset counter
96125
Log write Error-Select Disk in
Setup:
The system cannot locate the data
logging thumb drive to write new data
files
1. Go to
History>>Storage and
press Remove Disk.
2. Remove thumb
drive and reinsert.
3. If fault returns
contact DOD
Technologies, Inc.
96144
Custom Output Module Failure
The PC cannot communicate with the
I/O modules
1. Refer to the I/O
Verification
Procedure.
