TECHNICAL REFERENCE
L025317 Issue 1 March 2011 4-7
SPECIFICATION
D-Series Laser Marking System (10 Watt
Versions)
*Characters per second and production line speeds are substrate and code dependent
**Dimensions measured overall for shortest version
D-Series Models D120i 8mm Scan Head
Laser Power
10W (approx. 8W for Blue tube option @ wavelength of
9.3μm)
Laser Type
Sealed-Off CO
2
Laser, 30,000 hours MTBF
Wavelength 10.6μm typical (9.3μm as Blue tube option available)
Duty Cycle* 100%
Maximum Laser On
Time
No limit
Code Types Logos, bar codes, 2D codes, graphics, text, etc.
Characters per second* 800*
Product Line Speed*
200m/min*
650ft/min*
Character Height
0.6mm – field size
(0.02in – field size)
Focal Length 80, 100, 120, 150, 200mm
Marking Field
58x58 [mm],
68x68 [mm],
84x84 [mm],
102x102 [mm],
136x136 [mm]
Fonts 24 fonts, multi-language including full Unicode
Scan Head
i-Tech Scan Head, mountable in various orientations
including axial and radial
Laser Head Stainless steel and anodised aluminium construction
Dimensions **
(L x W x H)
681 x 140 x 180 [mm]**
26.8 x 5.5 x 7.1 [in])**
Weight 16.5 kg (36.4 lbs)
Operating Temp. 5º to 40º C (41º to 104º F)
Environmental
Humidity
Max. 90% RH, non-condensing
Cooling Air, Compressed Air
