INSTALLATION
2-46 L025317 Issue 1 March 2011
Achieving Maximum Line Speed
The D-Series includes a feature to extend the marking field when a moving
product is marked as it moves past the print head. This feature is used to
achieve maximum line speed.
Marking mode has to be configured for "Marking on the Fly".
Therefore adjust the marking mode via: System Setup, settings, Marking Engine,
Marking Mode
Normally the first object in the direction of movement of a message is marked
when it has entered the marking area below the laser lens.
Screen setup for Marking on the Fly
Product movement direction
Product
Marking field on product
Marking area
Example for Marking on the Fly without an extended field
