Domino D Series User Manual

OPERATION
3-16 L025317 Issue 1 March 2011
CONTROLS AND INDICATORS
The User Interface, Indicator Lamps and Software icon functions are
described in the following paragraphs:
Touchscreen and Interface
The software is operated via a PC keyboard, Touchscreen or Web Browser.
An entry is confirmed with the left mouse button if PC or Web browser are
used. The optional Touchscreen if connected, allows entry by touching the
tabs and function keys on the screen. An onboard keyboard is included in the
software.
Controls
ON / OFF BUTTON - Starts and stops the controller and PC unit
KEY SWITCH - Starts and stops the Laser Unit (fans and laser tube start).
The key switch has three positions
• "0" Laser off
•"1" Laser ready
• "*" Laser start.
On/Off
Button
Key switch
Indicator Lamps
