MAINTENANCE AND FAULT FINDING
L025317 Issue 1 March 2011 5-7
31 Scanhead
temperature out
of valid range.
The scanhead is cold. Wait for the heaters in the
scanner motors to warm the
scanners, the printer can be
used but you may experience
very minor position errors .
32 Scanhead
warming up -
please wait.
The scanhead is cold. Wait for the heaters in the
scanner motors to warm the
scanners, the printer can be
used but you may experience
very minor position errors.
33 Control unit over
temperature.
The temperature in
the controller is very
cold or too hot.
Check that the fans are
working and that the filters are
not blocked.
45 Laser cooling
defective
All systems but not
30W laser:
Wrong frequency
from fans/water
turbine was detected
in the laser head.
In case of 30W laser
the laser tube
detected a supply
voltage out of range.
Check all fans or water
turbines are connected and
working.
In case of 30W system check
that the controller contains a
30V power supply.
Check the path laser tube -
V30 interface board (there
LED V4 as error indicator) -
up to the controller.
51 Control unit near
over temperature.
The controller is
getting quite hot.
Check that the fans are
working and that the filters are
not blocked.
56 Printer ready to
print.
The printer is ready
to print if a print go
signal arrives.
Information Only.
58 No Message
loaded
There is no valid
message loaded into
the controller.
Load a message and send it to
printer.
549 Tu r n ke y sw i t c h
to enable marking
The safety relay needs
to be set after an
interlock has been
opened.
Turn the keyswitch to the start
position, or give a remote start
input (the "Play" button on
the user interface will not
function).
550 System disabled The keyswitch is at
position 0.
Turn the keyswitch to position
1.
Status Message Cause Suggested Action
