11. Electric system
187
Starter
General Information
The starter is attached to the back of the flywheel
housing. When disassembling the engine, immerse the
pinion gear and ring gear of the starter in fuel, brush
them, and then apply greases to them in order to prevent
rust.
Specification
• Starter should be protected from humidity all the
tim
e.
• Before working on the electric system, be sure to
disconnect the ground wire("-" minus wire) of the
battery. Short circuit may occur while working
on
t
he electrical system. Connect the ground wi
re
l
ast after completing all of work.
Specification
NOMINAL OUTPUT 24V, 7.0kW
ENGAGEMENT SYSTEM AUXILIARY ROTATION SYSTEM/SOFT START
Max. RATED TIME 30 SEC
ROTATION CLOCKWISE VIEWED FROM THE PINION
SWITCH HOLD-IN CURRENT
MAGNETIC SWITCH 2.3A
SOLENOID SWITCH 15A
