Connecting rod
Inspecting the connecting rod
1. Measure the parallelism between the connecting rod
small end’s bush hole and the large end bearing hole.
Here, use both the connecting rod measuring device
and feeler gauge.
DV2213162A_E
Item Standard Limit
Degree of parallelization 0.02mm 0.2mm
