11. Electric system
192
2) During Stop
2. Check of a voltage regulators: Mearsuring the resis-
tance between the terminals.
1) The resistance value between the voltage regulators.
Position Voltage
Terminal B - Body About DC27V ~ 29.5V
Terminal L - Body About DC27V ~ 29.5V
Terminal R - Body About DC3V ~ 5V
Position Voltage
Terminal B - Body About DC22V ~ 27V
Terminal L - Body About DC22V ~ 27V
Terminal R - Body 0
Terminal Resistance
+-
L Body
4 ~ 4.5 kΩ
R Body
110 ~ 180 kΩ
Body R
110 ~ 180 kΩ
LR
110 ~ 180 kΩ
