11. Electrical System
177
Circuit Diagram
EDX22190154
CAUTION
Run the alternator in accordance with the guidelines
provided in this chapter.
Regulator
Lamp terminal
Ignition terminal
Trio diode
Relay terminal
To battery (+) terminal
0.5 MFD
Circuit diagram
