Doosan DX22 - Outside Drawing of the Engine; Structural Diagram

3. Performance and Specifications
22
Outside Drawing of the Engine
Note) The images shown represent the standard model; they do not include all models.
Structural Diagram
EDX22190001
1. Lifting hook 5. Mounting bracket 9. Breather
2. Turbocharger 6. Coolant pump 10. Oil filler cap
3. Flywheel housing 7. Alternator 11. Starter Motor
4. Exhaust manifold 8. Intake manifold
3
6
1
2
4
5
9
8
11
10
