Doosan DX22 - Air Heater (Optional); Circuit Diagram; Operating Conditions

6. Cooling System
93
Air Heater (Optional)
Operating Conditions
EDX22190243
Circuit Diagram
EDX22190241
0
5
10
15
20
25
30
-30 -20 0-10 10 20 30 40
Temperature (°C)
Pre-heating time (sec)
0
50
100
150
200
250
300
350
-30 -20 0-10 10 20 40 5030 60
Temperature (°C)
Post-heating time (sec)
BATT PP
W
BATT
PP
T
C(Red) D(Black)
BATTERY(BATT) Terminal : M6 X 1.0 P
PP Terminal : M6 X 1.0 P
D(AVSS0.85 Black) C(AVSS0.85 Red)
