Dorma CS 80 MAGNEO Installation And Maintenance Manual

11DORMA
Driving direction open
Optional Power Cord
CS 80 MAGNEO
Control unit and connection
terminals for external accessories
8
7
6
5
4
3
2
1
ON
DIP switch
LED
light indicator
Potentiometer
hold-open time
Connection terminals for
external accessories
Mains switch
Energy mode switch
(Full-Energy/Low-Energy)
(located below the seal)
Potentiometer
speed adjustment
Reset button
Start
learning cycle
To reduce the risk of electric shock, this
equipment has a grounding type plug that
has a third (GROUNDING) pin.This plug
will only fit into a grounding type outlet.
If the plug does not fit into the outlet,
contact a qualified electrician to intall the
proper outlet.
DO NOT CHANGE THE PLUG IN ANY
WAY.
6. System Overview
Control unit and connection terminals for external accessories
Installation and Maintenance Manual
CS 80 MAGNEO
—

Dorma CS 80 MAGNEO Specifications

General

Brand	Dorma
Model	CS 80 MAGNEO
Category	Door Opening System
Language	English
