5. Functional Characteristics
5.1 General information
The CS 80 MAGNEO is a single-panel
Low-Energy-Modeslidingdooroperatorfor
small and light interior doors with an
admissible weight from 44 lbs to 175 lbs per
door panel. The opening and closing speed
respectively depend on the weight of the door
panel and can be adjusted via a
potentiometer (infinitely variable).
5.2 Commissioning
During the first commisioning of the operator,
the installer has to perform a learning cycle
according to the commissioning instructions.
When the installer connects the system to the
power supply (plugs it in) the light indicator
at the operator will blink and the operator
has no function. The door can be opened and
closed manually. Following the learning cycle
the light indicator goes on and the operator is
ready for operation.
5.3 Energy Modes (Maximum Force Limited)
With the aid of a sealed switch (located inside
the operator), the system can be switched
fromLow-Energy-ModetoFull-Energy-Mode.
Low-Energy-Mode
The standard ANSI 156.19 states the energy
with which a swing door panel hits an obstac-
le must be limited. The CS 80 MAGNEO
operator moves the sliding panel at a low
speed corresponding to ANSI 156.19 energy.
The potentiometer (located inside the opera-
tor) can only be used to reduce this calcula-
ted speed.
Full-Energy-Mode
The forces are limited in this mode as well.
The speed is infinitely variable with the aid of
a potentiometer (located inside the operator).
Even though the door may open at a fast
speed. The closing cycle always remains in
Low-Energy-Mode
5.4
Operation modes
OFF: The operator is switched off.
You can move the door by
hand.
AUTOMATIC: When the system has been
activated via pushbutton,
radio remote control or
similar, the operator opens
the door and closes after
expiration of the adjusted
hold-open time.
PERMANENT
The operator opens the door
OPEN: and holds it in “open“ posi
-
tion until it receives an other
signal.
When the system is delivered, the
CS 80 MAGNEO is adjusted to AUTOMATIC
Mode.
An external program switch is required to
change the operation mode.
5.5 Functions in AUTOMATIC Mode
Push & Go
As soon as the door is moved manually into
opening direction by approximately 3/8”
[10 mm], the operator will automatically
move the door panel further in the desired
direction. The door closes automatically.
Permanent Open via double-click
A double-click on the push button (activate
the pushbutton twice in quick succession)
will open the door. When you double-click on
the button for a second time or move the door
panel by hand, the door will close.
Opening/closing via pushbutton
As soon as you push the button or move the
door manually the door will open. When you
push the button for a second time or move
the door panel by hand, the door will close.
Installation and Maintenance Manual
CS 80 MAGNEO
—
