Mounting procedure
If there is a door frame, you have
to shim the angle brackets with
the shim plate (optional).
1.
Auxiliary lines for positioning pur
-
poses. See bottom of this page.
2.a Installation without shim plate.
See Page 16 and 17.
2.b
Installation with shim plate.
See Page 18.
3. Further installation.
See Page 19 - 22.
Positioning Guide
For the installation without
shim plate mark the center of
the passage on the wall.
For the installation with shim
plate mark the center of the
passage on the wall. Please
have a look at the table for the
required dimension M for your
operator.Lcorrespondstothe
operator length.
Now mark the reference line.
Always mark the reference
line on the side of the main
closing edge.
34.4“ [875] 39.4” [1000] 44.3” [1125]
L
68.9“ [1750] 78.7“ [2000] 88.6“ [2250]
M
17.2“ [437.5] 19.7“ [500] 22.1“ [562.5]
In case the door panel
shall not be positioned in
the center of the passage,
the bracket or shim plate
has to be shifted by the
desired dimension.
==
Reference
line
Main closing edge
M
**Dimensions marked (=) are equal.**
Glass door panels with
MANET single-point fixings
Door panel information
Secondary closing edge
Main closing edge
8. Installation instructions for on-wall mounting
41.33" or other dimension
1050 mm or other dimension
Edge grinded glass
=C=
CENTERED
2.5" [63 mm]
2.2" [55 mm]
Glass width
Drill hole for
recessed door grip
(optional)
at least 2.76"
at least 70 mm
Operator lengthC
68.9" [1750] 22.7" [575]
78.7" [2000] 27.6" [700]
88.6" [2250] 32.5" [825]
„Closed“ side
Ø 1.03" [Ø 26) hole
C‘Sink Ø 1.26" [Ø 32] X 90°
Glass height = H - 5" [12 mm]
90°
90°
Ø 1.97" [Ø 57) hole
C‘Sink Ø 2.05" [Ø 52] X 90°
max.
.31"
8 mm
Angle
floor guide rail compl.
.250"
6 mm
Finished floor
2.5"
62 mm
at least .2"
at least 5 mm
Installation type
On-wall-mounting
