100 Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n
Operating concept
If a state is reached in which a parameter cannot be changed any more, the device
displays a corresponding message in the notification field (3).
5.1.4 Quick setup dialog
Depending on the parameter field or waveform, this dialog contains various setting
possibilities, e.g., for limits or scales.
This dialog can be opened by touching the corresponding parameter field in the
monitoring area. This dialog can be configured so that it opens automatically in the
event of an alarm, see page 208.
5.1.5 Screen saver
A screen saver is activated if no operation takes place for more than 5 minutes and
30 seconds when in standby mode. The screen saver can be ended by touching the
screen or another screen control element. The screen saver is ended automatically
if an alarm message with medium or high priority appears.
The screen saver can be activated or deactivated in the system setup (see "Vertical
tab "General"", page 204). Dräger recommends leaving the screen saver activated
in order to prevent possible damage to the screen due to permanent still images.
34767
